LED 幻彩 流水灯带

1. Product model: WS2811 Colorful Light Bar, 1 meter, 20 segments, 60 lights;

2. Light source: SMD 5050 LED;

3. Board: FPCB;

4. Chips: Taiwan Semiconductor Manufacturing Company chips, as well as other chips from Taiwan;

5. IC model: WS2811, (20 ICs per meter, 1 IC controls 3 LED lights);

6. Grayscale level: 256 levels, (20 pixels per meter);

7. LED quantity: 60 lights/meter, with 3 lights per group, can be cut;

8. Luminous angle: 180 °;

9. Luminous color: can be adjusted through the controller to white, red, yellow, blue, green, etc;

10. Standard operating voltage: DC 12V;

11. Power: 18W ± 10%/meter;

12. Waterproof level: non waterproof, drip glue (IP65), sleeve (IP67), solid glue filled sleeve (IP68), etc;

13. Dimensions of FPCB board: Width: 12mm, Thickness: 4mm;

14. FPCB colors: white, yellow, black (except for white, customization is required);

15. Packaging method: 5 meters per roll, with 3M adhesive backing behind the light strip and sealed in an electrostatic bag;

16. Weight: 0.185g/roll (not waterproof);

17. Packing: 50 rolls/box. Box size: 450 * 330 * 310 (mm), weight: 14.5KG;

18. Our company can provide matching iridescent controllers and power supplies
